智能鞋方案开发

2019-04-13 10:48:12

智能鞋方案开发


    智能鞋顾名思义,就是有智能功能的鞋子。智能鞋是一个跨领域的产品,它的基础是鞋,但又承载了智能科技产品的特性。

  智能鞋的功能

  1、光亮控制,在鞋底、鞋底外周缘、鞋邦面三部分分别设有LED灯或类似EL冷光图案,电路分别控制这三组发光件,常亮、快闪、慢闪轮流亮等。发光提亮度可控。

  2、计步器功能,可计算步数、行走距离。可计算一段周期内结果,如按天、周、月、年。也可从现在即起计算。脚底按摩功能。鞋底内置震动马达,震动力度可分5档,按摩时可选档,来电提醒可事先设定档位。

  3、来电提醒、短信提醒。(预留微信、QQ、微博提醒接口)提醒方式:双鞋同时震一秒又停一秒,如是者三次。上述方式是为了更好地兼容脚底按摩时来电的情形,温度控制,自动断电保护;极端情况下如进水短路能自动断电保护。

  4、鞋内通风去脚气,此功能适用于休闲鞋,不用在凉鞋上,但内置微型风扇的另一作用降低鞋底内设备温度用。硬件温度高时开启通风,平时设置开一段时间关一段时间,手机APP可控:强—中—弱三档可选。通风功能运行时间长后,鞋内空间易有积尘,影响鞋内电子设备正常运行,故对鞋内各设备如电路板、电池、震动马达、LED灯的发热情况要分别对待,如电路板部分能长时间工作发热量不大,则通风通道可不经电路板部分,避免电路板的积尘。

   智能鞋的特性 

   1.智能运动:除基本的计步、步频、轨迹、里程、热量消耗等数据量化功能,可增加运动检测与分析功能。智能运动鞋相对手机和手表手环等有的优势就是无需额外的佩戴产品在身上,所有量化数据都可记录在鞋智能模块里,运动完成后可同步至手机或云服务器进行分析和反馈。  

   2.保障性:近年来儿童的安全备受关注,增加儿童鞋追踪模块,具有其隐蔽性和可靠性。通过GPS和移动网络的连接,可随时定位;通过短距离通信的方法和移动网络连接,可设置电子围栏,解放家长的注意力;还可以设置儿童主动安全功能,当遇到特殊情况,可通过隐蔽性的方法通知家长。  

   3.健康医疗:测量基本的血压、心率、体重、体温等数据,使得大众能够随时监测自己的基本健康情况,除此,工作在外的子女也可以远程随时的地取父母的数据,通过实时和长期的数据分析, 及时跟踪父母的健康状态及紧急情况自动通知等。  

   4.游戏娱乐:通过运动检测功能,获得运动交互的数据,结合VR、游戏等进行人机交互。


图片关键词


Development of Intelligent Shoe Scheme

Smart shoes, as the name implies, are shoes with intelligent functions. Smart shoes are a cross-domain product, which is based on shoes, but also bears the characteristics of intelligent technology products.

Functions of Smart Shoes

1. Brightness control. There are LED lights or EL-like cold-light patterns in the sole, the outer edge of the sole and the upper of the shoe. Circuits control these three sets of light-emitting components, such as constant light, flash, slow flash, etc. The brightness can be controlled.

2. The pedometer function can calculate the number of steps and walking distance. The results of a period of time can be calculated, such as by day, week, month and year. It can also be calculated from now on. Foot massage function. The shoe sole has built-in vibration motor. The vibration intensity can be divided into five grades. When massaging, the gear can be selected. Call reminder can set the gear beforehand.

3. Call reminder and short message reminder. (Reserve Weixin, QQ, Weibo reminder interface) Reminder mode: shoe shocks one second and stops one second at the same time, if so three times. The above way is to better compatible with the foot massage calls, temperature control, automatic power-off protection; in extreme cases, such as water short circuit can automatically power-off protection.

4. Ventilate inside shoes to get rid of beriberi. This function is suitable for casual shoes, not sandals, but the other function of the built-in micro fan is to reduce the temperature of the equipment inside the sole. When the hardware temperature is high, the ventilation is turned on and off for a period of time. The mobile phone APP is controllable: strong - medium - weak three gears are optional. When the ventilation function runs for a long time, the space inside the shoes is liable to accumulate dust, which affects the normal operation of the electronic equipment inside the shoes. Therefore, the heating conditions of the equipment inside the shoes, such as circuit boards, batteries, vibration motors and LED lamps, should be treated separately. If the heat generated by the circuit board part can work for a long time is small, the ventilation passage can avoid the dust accumulated by the circuit board part.

Characteristics of Smart Shoes

1. Intelligent motion: In addition to the basic data quantification functions such as step counting, step frequency, trajectory, mileage and heat consumption, it can increase the function of motion detection and analysis. Compared with mobile phones and wristbands, smart sneakers have some advantages, such as no additional wearing products on the body. All quantitative data can be recorded in the smart module of shoes, and can be synchronized to mobile phones or cloud servers for analysis and feedback. Chinese style

2. Guarantee: In recent years, children's safety has attracted much attention. Adding children's shoes tracking module has its concealment and reliability. Through the connection of GPS and mobile network, it can be positioned at any time; through short distance communication and mobile network connection, it can set up electronic fence to liberate parents'attention; it can also set up children's active safety function, when encountering special circumstances, parents can be notified by concealment method. Chinese style

3. Health care: Measure basic blood pressure, heart rate, weight, body temperature and other data, so that the public can monitor their basic health at any time, in addition, children outside the work can also remotely and anytime access to their parents'data, through real-time and long-term data analysis, timely tracking of parents' health status and emergency automatic notification, etc. Chinese style

4. Game Entertainment: Through the function of motion detection, the data of motion interaction can be obtained, and human-computer interaction can be carried out in combination with VR and games.
