Le tableau de commande de fer électrique intelligent est un tableau de commande sûr et compact pour les produits de fer électrique. Le tableau de commande de fer électrique utilise un certain nombre d
Le tableau de commande de fer électrique intelligent est un tableau de commande sûr et compact pour les produits de fer électrique. Le tableau de commande de fer électrique utilise un certain nombre de technologies matures telles que le circuit intégré de contrôle dédié, la conversion de tension sans transformateur et la protection de mise hors tension automatique. Ce tableau de commande a les fonctions de mise hors tension automatique et d'arrêt du chauffage lorsqu'il est placé horizontalement pendant 30 secondes et verticalement pendant 8 minutes.
Utilisez plus sûr pour empêcher les criminels d'incendie:
Autrement dit, lorsque le fer est plat et immobile, il entrera dans la protection de mise hors tension automatique après 30 secondes. Lorsque le fer est à l'arrêt, il entrera dans la protection de mise hors tension automatique après 8 minutes. Après avoir activé la protection de mise hors tension automatique, le fer à repasser arrête immédiatement de chauffer et le voyant lumineux clignote. Lorsque vous souhaitez utiliser un fer à repasser électrique, vous pouvez immédiatement le mettre sous tension et travailler.
Les principaux paramètres techniques:
1. Tension / fréquence de travail nominale: 230VAC / 50Hz;
2. Puissance nominale: puissance de la plaque chauffante 1200W ～ 2200W
3. Température de l'environnement de travail: -20 ℃ ～ + 60 ℃
4. Erreur de synchronisation: une erreur de synchronisation de 30 secondes est inférieure à 1 seconde, une erreur de synchronisation de 8 minutes est inférieure à 10 secondes
5. Exigences de certification: SGS, UL, VDE.
Test de mise sous tension de la carte de commande des petits appareils:
1. Vérifiez si le câblage du circuit est correct ou non et assurez-vous que le câblage est correct avant la mise sous tension;
2. Après la mise sous tension, le voyant est allumé et le fer à repasser fonctionne normalement. Lorsque le fer est en utilisation normale (état en mouvement, repassage des vêtements), le voyant est toujours allumé;
3. Lorsque le fer est à plat, il entre dans la protection de mise hors tension automatique après 30 secondes, le fer arrête immédiatement de chauffer et le voyant lumineux clignote pour indiquer;
4. Lorsque le fer à repasser électrique est immobile, il entre dans la protection de mise hors tension automatique après 8 minutes. Le fer à repasser électrique arrête immédiatement de chauffer et le voyant clignote;
5. Lorsque le fer doit être utilisé, tant qu'il est déplacé, il peut être immédiatement mis sous tension pour le chauffage.
Intelligent electric iron control board is a safe and compact control board for the application of electric iron products. The iron control board uses many mature technologies such as special control IC, transformer-free voltage conversion, automatic power-off protection and so on. The control panel has the functions of 30 seconds, 8 minutes automatic power off and stopping heating.
Use safer methods to eliminate hidden fire criminals:
That is, when the iron is flat and still, it enters the automatic power-off protection after 30 seconds, and when the iron is standing upright, it enters the automatic power-off protection after 8 minutes. After entering the automatic power-off protection, the electric iron stops heating immediately and the indicator flashes. When the iron is to be used, it can be heated immediately.
Main technical parameters:
1. Rated operating voltage/frequency: 230VAC/50Hz;
2. Rated Power: Heating Disk Power 1200W-2200W
3. Working Environment Temperature: -20 ~+60
4. Timing error: 30 seconds timing error is less than 1 second, 8 minutes timing error is less than 10 seconds
5. Authentication requirements: SGS, UL, VDE.
Electricity test of small household appliances control board:
1. Check whether the wiring mode of the circuit is correct or not, and ensure that the wiring is correct before the power can be turned on;
2. After power-on, the indicator lights on and the iron bucket works normally. When the electric iron is in normal use (moving state, ironing clothes), the indicator light is always on.
3. When the iron is flat and still, it enters the automatic power-off protection after 30 seconds. The iron stops heating immediately and the indicator flashes.
4. When the iron is standing vertically, it enters the automatic power-off protection after 8 minutes. The electric iron stops heating immediately and the indicator flashes.
5. When an electric iron is to be used, as long as the electric iron is moved, it can be heated immediately by electrification.
