Control remoto bluetoothdescripciónLos televisores con control remoto y los decodificadores pueden combinarse con air mouse, funciones somatosensoriales, funciones de transmisión de voz unidireccional
Control remoto bluetooth
descripción
Los televisores con control remoto y los decodificadores pueden combinarse con air mouse, funciones somatosensoriales, funciones de transmisión de voz unidireccional y funciones táctiles de acuerdo con las definiciones del cliente. La forma es pequeña y exquisita, y el agarre es cómodo.
Ventaja
1. La distancia de trabajo normal es de al menos 15 m, la distancia máxima de recepción es de 40 metros.
2. Para satisfacer las necesidades del cliente, cuando se lanza una nueva versión del firmware del control remoto, el control remoto en la mano del usuario se puede actualizar de forma inalámbrica a través de Bluetooth.
3. Diseño único, de acuerdo con la definición de ergonomía, el diseño está estrictamente de acuerdo con el tamaño de la mano, lo que hace que el usuario se sienta más cómodo al usar el control remoto.
Características del producto:
Los televisores con control remoto y los decodificadores pueden combinarse con air mouse, funciones somatosensoriales, funciones de transmisión de voz unidireccional y funciones táctiles de acuerdo con las definiciones del cliente. La forma es pequeña y exquisita, y el agarre es cómodo.
Caracteristicas
1. La distancia de trabajo normal es de al menos 15 m, la distancia máxima de recepción es de 40 metros.
2. Para satisfacer las necesidades del cliente, cuando se lanza una nueva versión del firmware del control remoto, el control remoto en la mano del usuario se puede actualizar de forma inalámbrica a través de Bluetooth.
3. Diseño único, de acuerdo con la definición de ergonomía, el diseño está estrictamente de acuerdo con el tamaño de la mano, lo que hace que el usuario se sienta más cómodo al usar el control remoto.
Parámetros técnicos:
Parámetros específicos de la categoría
Protocolo de transmisión BT4.0LE
Método de modulación GFSK
Rango de frecuencia RF: 2402-2483 MHZ
Voltaje de funcionamiento: 2,2 V-3,6 V
Corriente de espera en reposo: <40uA
Corriente de trabajo clave: <10mA
Corriente de trabajo táctil: <10mA
Corriente de trabajo del mouse vacío: <15mA
Corriente de trabajo de voz: <27mA
Potencia de transmisión-20dbm ~ 10dbm
Sensibilidad de recepción: <-70dbm
Compensación de frecuencia portadora, compensación de deriva <± 150 KHz, tasa de deriva <20Khz / 50us, deriva <50KHz
Ganancia de la antena> -2,5 dB
Bluetooth Remote Controller
describe
Television sets and set-top boxes can match empty mice, somatosensory functions, one-way voice transmission functions and touch functions according to customer definitions. Small and delicate shape, comfortable grip.
advantage
1. Normal working distance is at least 15m; maximum receiving distance is 40m.
2. In line with customer needs, when a new version of firmware for remote control is released, the remote controller in the user's hand can be upgraded by Bluetooth wireless.
3. Style design is unique. According to the definition of ergonomics, the design is strictly in accordance with the size of the hand, which makes the user more comfortable when using the remote control.
Product characteristics:
Television sets and set-top boxes can match empty mice, somatosensory functions, one-way voice transmission functions and touch functions according to customer definitions. Small and delicate shape, comfortable grip.
Functional characteristics
1. Normal working distance is at least 15m; maximum receiving distance is 40m.
2. In line with customer needs, when a new version of firmware for remote control is released, the remote controller in the user's hand can be upgraded by Bluetooth wireless.
3. Style design is unique. According to the definition of ergonomics, the design is strictly in accordance with the size of the hand, which makes the user more comfortable when using the remote control.
Technical parameters:
Categories: Specific parameters
Transport Protocol BT4.0LE
Modulation mode GFSK
RF frequency range: 2402-2483 MHZ
Working Voltage: 2.2V-3.6V
Static Standby Current:<40uA
Key Working Current:<10mA
Touch current:<10mA
Working Current of Air Rat:<15mA
Voice working current:<27mA
Transmitting power - 20 dbm~10 dBm
Receiving sensitivity: <-70 dBm
Carrier frequency offset, drift < 150KHz, drift rate < 20Khz/50us, drift < 50KHz
Antenna gain > - 2.5dB
