三合一同步整流移动电源方案

三合一同步整流移动电源方案

LCD/LED电量指示，主要功能有：

电池充电管理，锂电池升5V

放电，充放电量；ED/LCD指示。

输入5V/1A充电

输出5V/2．1A放电

检测负载过流短路及温度保护

功能

标准锂电池充放电管理控制及

电量指示（LCD/LED）

Three-in-one Synchronized Rectification Mobile Power Supply Scheme

LCD/LED power indicator, the main functions are:

Battery charging management, lithium battery up to 5V

Discharge, charge and discharge; ED/LCD indication.

Input 5V/1A Charging

Output 5V/2.1A Discharge

Detection of Overcurrent and Short Circuit of Load and Temperature Protection

function

Charge and Discharge Management and Control of Standard Lithium Batteries

Electricity Indicator (LCD/LED)
